• Field testing mode to evaluate Network quality
• Support LoRaWAN packet re-transmission if lost(need configured)
• Support Relay function to forward the LoRaWAN class A message of slave node(need configured)
• IP67 protection
• Operation range; -40~85℃
• Bluetooth APP to enable device management and control and Upgrade over the air.
• Optimized power consumption, typical for 5 year battery life.
• Low battery level alarm, Battery is capable to change, ER34615 size.
• Besides LoRaWAN, there is also Cat-1/Cat-M version for customer's choice.

Technical Specifications

Item	Name	Specification
Mechanical specifications	Product size	110*47*57.8mm
	weight	233g
Wireless Communication	LPWAN Network connection	LoRaWAN
		Cat-1 (optional)
		Cat-M (optional)
	WLAN Wireless configure	BLE
Electrical properties	Power supply	ER34615 Lithium Thionyl Chloride battery
	Battery Voltage	3.6v
	Battery capacity	19Ah
	Typical battery lifetime*	5 years
	Standby current	50uA
	Peak current	155mA
	Maximal LoRa output power	21dBm@868MHz 21dBm@470MHz 21dBm@915MHz
	LoRa receiving sensitivity	-138dBm@SF12, BW=125kHz
Sensors	Temperature- humidity sensor	Monitor external environmental Temperature humidity
	Hall sensor	Act as Switch on/off button with a magnet
	3-axis acceleration sensor	Step counting
Operating environment	Operating temperature range	-40 to +85°C
	Storage temperature range	-40 to +85°C

Power supply specification

Battery type	ER34615
Nominal Capacity	19Ah (The capacity of a battery is also related to discharge current, temperature, and termination voltage)
Nominal voltage	3.6V
Maximum continuous discharge current	230mA
Maximum pulse current	400mA
weight	107g
